Climax Offroad Long Travel Suspension Kits

Max A.

Well-known member
Joined
Nov 4, 2019
Messages
584
Points
93
Location
Baltimore, MD, USA
Roxor Ownership
Roxor Owner
Roxor #
00168
Update. Rubicon Express is officially out of business. Springs seem to still be readily available. The RE number for bushings is out of stock everywhere.

*The long travel kit uses 9/16 leaf spring bolts. 1/2 bolts will work but 9/16 is ideal.

Here are alternative options.

non greasable

RuffStuff part number - R1957 (you will need 8 and (8) 9/16 bolts)

or greasable bushings

KJ02023 (you will need 2 kits)

-----------------------------------------------------------------------

- Zone/BDS springs are a tad soft for a roxor and I do not recommend them if you have a bunch of accessories.

- Rough County springs are cheap but you get what you pay for. I would not suggest them if you use off-road.

- Rustys Offroad makes 4 inch lift springs that should work and come with bushings installed. P# RC-LS400F-YJ (not sure of bolt size)

- SkyJacker ROCK READY YJ springs will work with the kit and I have ran them myself and was very happy with them. P3 YJ45FS

- A spring that is untested is Pro Comp 2.5 Inch Front Leaf Spring - 11211 this will bolt up but I'm insure of the spring rate you may need to add
a leaf. this is also not a military wrap spring from what I can tell.

- There are many other options out there.

*** If you find any spring is too soft with all of your accessories weighing your Roxor down you can add a leaf using ProComp Part # EXP13120

---------------------------------------------------------------------------------------------------


TomRox

Active member
Joined
Apr 15, 2023
Messages
137
Points
28
Location
Colorado
Roxor Ownership
Roxor Owner
Roxor #
8164
What shock valving rate is suggested ?
bilstien has 2 rates

255/70
170/60

very early in this thread it seems the shocks recommended were 170/60


TomRox

Active member
Joined
Apr 15, 2023
Messages
137
Points
28
Location
Colorado
Roxor Ownership
Roxor Owner
Roxor #
8164

Anybody try to mount the rear shocks here like this wrangler YJ? Seems too tight on room

Thoughts? Longer travel shocks could be installed w this set up


txroadkill

Well-known member
Joined
Oct 28, 2018
Messages
1,226
Points
113
Location
Texas
Roxor Ownership
Roxor Owner
Roxor #
2498
picked up the Roxor from the shop that put the lift in. I’m amazed at the difference in flex and ride quality. Wished I did it sooner. I am shocked that I was bump stopped perfectly for my 33s and I think even 35s. Now they need to be extended longer. I guess the Geometry changed with the dropping of the suspension hangers. Easy fix that I’ll do myself.


TomRox

Active member
Joined
Apr 15, 2023
Messages
137
Points
28
Location
Colorado
Roxor Ownership
Roxor Owner
Roxor #
8164
Txroadkill- what shocks do you have up front?
The shop has mine almost finished today

Need to pick some front shocks



TomRox

Active member
Joined
Apr 15, 2023
Messages
137
Points
28
Location
Colorado
Roxor Ownership
Roxor Owner
Roxor #
8164
These?

Front shocks - 33-104645
Rear shocks- 33-230443


Max A.

Well-known member
Joined
Nov 4, 2019
Messages
584
Points
93
Location
Baltimore, MD, USA
Roxor Ownership
Roxor Owner
Roxor #
00168
Unfortunately there just isn't much clearance for socks outboard of the frame. I do have extended shock towers available but they only work with axle swaps.


txroadkill

Well-known member
Joined
Oct 28, 2018
Messages
1,226
Points
113
Location
Texas
Roxor Ownership
Roxor Owner
Roxor #
2498
BUMP STOPS;

2.5RE springs and a cecco body lift
33’s bumpstopped for future 35s.









REAR: Some 3” tubing bolted to the rear frame works great for bumpstops. Thought I had them perfect for future 35s but the stock rubber bumps squished and fender cutting on the lower rear corner will be required for 35s. On the forklift they were fine, when I drove it on the trailer is when I discovered the squish. 33s clear just fine.







FRONT: used the same 3” tubing but narrowed it to 2” wide like the factory stop width and made them 7” long to extend the stops forward about an 1.5” to go with the axle stretch. They look to be good for 35s and I don’t think the stops will squish down like the rears did.





wpatter

Member
Joined
Jul 23, 2020
Messages
75
Points
18
Location
Little Rock, AR, USA
Roxor Ownership
Roxor Owner
Roxor #
6624
What kind of shop are you guys getting to assemble and install these kits for you? I have ambitions to install my own but my buddy's lift is always being used by others.


txroadkill

Well-known member
Joined
Oct 28, 2018
Messages
1,226
Points
113
Location
Texas
Roxor Ownership
Roxor Owner
Roxor #
2498
I took mine to a local automotive/4x4/4x4 fab shop.


wpatter

Member
Joined
Jul 23, 2020
Messages
75
Points
18
Location
Little Rock, AR, USA
Roxor Ownership
Roxor Owner
Roxor #
6624
@Max A. I'm sorry and need a little help. I can't seem to find these anywhere:

non greasable

RuffStuff part number - R1957 (you will need 8 and (8) 9/16 bolts)

or greasable bushings

KJ02023 (you will need 2 kits)

Not searching, not on Ruffstuff's site or anywhere else. However, when I searched for the RE springs it showed the Daystar JK02007BK as an add on option and notes it's for the 87-95 Jeep Wrangler YJ. Of course the ID isn't anywhere I look either...


Max A.

Well-known member
Joined
Nov 4, 2019
Messages
584
Points
93
Location
Baltimore, MD, USA
Roxor Ownership
Roxor Owner
Roxor #
00168
@Max A. I'm sorry and need a little help. I can't seem to find these anywhere:

non greasable

RuffStuff part number - R1957 (you will need 8 and (8) 9/16 bolts)

or greasable bushings

KJ02023 (you will need 2 kits)

Not searching, not on Ruffstuff's site or anywhere else. However, when I searched for the RE springs it showed the Daystar JK02007BK as an add on option and notes it's for the 87-95 Jeep Wrangler YJ. Of course the ID isn't anywhere I look either...


and

Replacement Bushing

use the drop down menu to select 3 x 9/16


Chase F

New member
Joined
May 14, 2024
Messages
4
Points
1
Location
idaho
Roxor Ownership
Roxor Owner
Looking for someone who has done the yj stock level springs on the long travel kit. hoping someone has a parts list and the shocks used for this application.


txroadkill

Well-known member
Joined
Oct 28, 2018
Messages
1,226
Points
113
Location
Texas
Roxor Ownership
Roxor Owner
Roxor #
2498
Looking for someone who has done the yj stock level springs on the long travel kit. hoping someone has a parts list and the shocks used for this application.
I believe @TomRox went that route.


TomRox

Active member
Joined
Apr 15, 2023
Messages
137
Points
28
Location
Colorado
Roxor Ownership
Roxor Owner
Roxor #
8164
I went with 1.5” springs from super lift
I ended up with 2 3/4” lift in front and 1.5” in back
33” tires
I put generic Amazon 2” universal Jeep bump stops in front, vs the 1” factory

For shocks running the 33 series Bilstiens

Your limit will be the compressed length, you want the bump stops to touch prior to full compression of the shock,

You may want to check full droop extension
Compressed and extended length
Or
33-185590 would work If you don’t want to overthink it
